4.3 Left (MC1), Right (MC2) Buttons
The left and right buttons are used to change the operation program screens the left (MC1) and right (MC2) embroidery
machine.
- Left (MC1) embroidery machine button
- Right (MC2) embroidery machine button
4.2.1 Design information
4.2.2 Machine information
Title(Ex)No. Description Ref.
152NAME(No.)
Name and memory # of the selected design
12,552STITCH
No. of total stitches in the selected design
137.2X(mm)
X length of the selected design (mm)
116.7Y(mm)
Y length of the selected design (mm)
3COLOR
No. of colors in the selected design
29JUMP
No. of jumps in the selected design
0ANGLE
Degree of design rotation
NOMIRROR
Yes/No of mirror function
100[%]X SCALE
% of X-axis enlargement
100[%]Y SCALE
% of Y-axis enlargement
3TOTAL WK
Total no. of work plates. Number increases after each plate is done.
0X POS
Current location on X axis
0Y POS
Current location on Y axis
YES : Yellow
NO : Green
ORIGIN
It means that the frame has returned to the work starting point.
Title(Ex)No. Description Ref.
1/1NEEDLE
Current needle bar / Next needle bar
2240TOTAL ST
No. of stitches accumulated so far
FIXPOSFIXPOS
Stop position of the main axis
[WARNING] Needle bar must be changed at 100°
00:00EMB_TIME
Embroidery time (hour/minute)
0 / 0 %STITCH
No. of stitches made/ Percentage of progress
