SWF Dual Function E Series - Machine Setting and Troubleshooting (※Dual Function 1×1 Embroidery Machine); Rear Side of Control Box


7.2.0 Machine Setting and Troubleshooting (
※※
Dual Function 1
××
1 Embroidery Machine)
7.2.1 Rear Side of Control Box
<Fig. 7.2.1-1> shows the rear side of the Control Box.
 MC1 Main Driver
 MC2 Main Driver
 MC1 I/O Board, XY Driver
 MC2 I/O Board, XY Driver
[Fig.7.2.1-1]

