SWF Dual Function E Series


[Ex.5.9.5-3] Design start position: X (500) Y (300)
Offset middle point: X (1000) Y (1000)
Design offset point: X (1500) Y (1700)
󱀣 Press Frame Offset Setting in the setting menu.
You will see [Fig.5.9.5-1].
󱀤 Press Design Start Point.
You will see the menu activated.
󱀥 Use the frame movement keys to set X and Y positions.
󱀦 Press Offset middle point and the menu will be activated.
󱀧 Use the frame movement keys to set X and Y positions.
󱀨 Press Design offset point and the menu will be activated.
󱀩 Use the frame movement keys to set X and Y positions.
󱀪 Press .
