Symmetricom TimeHub 5500 System Manual

100 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
Table 4-1. Typical Oscilloscope Settings
Control Setting
Mode Trigger Switch ADD
Invert Switch INVERT
Ch1 and Ch2:
Volts/Div
Input Coupling
Vert Position Control
See Note
AC
mid-range
A Sweep Mode AUTO-TRIGGER
Horizontal Display Switch A
Time/Div Switch:
for CC
for DS1
20 µs
500 ns
A Sweep FULL
Horizontal Position Control mid-range
A Triggering:
Slope
Coupling
Source
+ or –
AC
INT
Note: Adjust the oscilloscope’s volts-per-division scale to the
appropriate level to get a measurable pulse amplitude on the screen; for
example, to measure a 0 dB DSX (TERM) signal, set the volts-per-
division scale to 1 V per division; to measure a -20 dB DSX (BRDG)
signal, set the volts-per-division scale to 100 mV per division.
