Maintenance
5.2.4 EC Card
To replace the EC card, follow the steps in Procedure 5-4, and refer to
Figure 5-4.
Procedure 5-4. EC Card Replacement
Step Action
1 Put on a properly grounded ESD wrist strap.
2 Using a #2 Phillips-head or Pozidrive screwdriver, loosen the captive screws at the top and
bottom of the card front panel.
3 Remove the card from the shelf.
4 Insert the replacement card into the shelf: ensure that the card aligns properly with its
mating backplane connector; push the card into place until it is fully seated into the
backplane connectors.
5 Wait for the Power lamp to light, the Shelf Power and Expansion Links lamps to light, and
the Fail and Alarm lamps to turn off.
6 Press the Cutoff pushbutton on the management card several times.
7 Verify that any alarm conditions are cleared.
8 Tighten the captive screws at the top and bottom of the card front panel.
End of Procedure
