Symmetricom TimeHub 5500 System Manual

126 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
Figure 4-11. DS1 Output Waveforms
Figure 4-12. CC Output Waveforms





















648 ns
±0.05%
Pulse Rise Time
<150 ns
324 ns
±50 ns
100% V = 2.4 V TO 3.6 V
0 V
0 250 500 750
100% V
50% V
Test load impedance: 100
Ω
for 22 AWG
twisted pair cable.
15.625
µ
s ±5%
9.8
µ
s ±5%
–
2.7 V TO -5.5 V
2.7 V TO 5.5 V
Bipolar
violation
Bipolar
violation
Pulse rise time <500 ns
Test load impedance: 133
Ω
for 22 AWG twisted pair cable
125
µ
s
7 8 2 4 6
87531
