Symmetricom TimeHub 5500 System Manual

82 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
Figure 3-6. Shelf Rear with Connector Modules
3.6.2 Output Connector Module (Master and Remote
Shelf Only)
Install the appropriate output connector module (Figure 3-7) type.
• For DS1 outputs, use DS1 Output Connector modules (part
number 090-55591-01), which are part of the DS1 Output
Connector Module Kit (990-55591-01) (Figure 3-7A).
• For CC outputs, use CC Output Connector modules (part number
090-55593-01), which are part of the CC Output Connector Module
Kit (990-55593-01) (Figure 3-7B).
Input/Alarm
Connector Module
Output
Connector Modules
