168 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
5.1.3 Management Card
Management card front-panel items are shown in Figure 5-3. The items are
described in Table 5-3.
Ports 1–20
CC
Off There is no connector card
connected to ports 1 through
20, no outputs can be
generated.
None required.
Green There is a CC connector card
connected to ports 1 through
20.
None required.
Ports 21–40
DS1
Off There is no connector card
connected to ports 21 through
40, no outputs can be
generated.
None required.
Green There is a DS1 connector card
connected to ports 21 through
40.
None required.
Ports 21–40
CC
Off There is no connector card
connected to ports 21 through
40, no outputs can be
generated.
None required.
Green There is a CC connector card
connected to ports 21 through
40.
None required.
Table 5-2. Output Driver Card Front Panel Items (Cont’d)
Name State Description
Action
