097-55501-01 Issue 6 – June 2003 169
2
5
3
Maintenance
Figure 5-3. Management Card Front Panel
Captive Screws (4)
Power
Alarm
Fuse
Fail
SHELF POWER –48V
A Fail B Fail
ALARMS
Minor
Major
Critical
System
Shelf
Cutoff
PASSTHROUGH
Active
COMM PORTS
Local
Remote
Link
Logon
Xmit
Local
