Symmetricom TimeHub 5500 System Manual

68 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
Table 2-1. Master and Remote Shelf Basic Components
Item Part Number Qty Included Items
Master shelf kit 090-55500-01 1 • Master shelf (090-55501-03)
• Wirewrap input module
(090-55561-01)
• Wirewrap panel (190-55595-01) x 1
• 19 in. and 23 in. mounting hardware
• System manual
Management
card kit
090-55542-01 1 • Management card (090-55542-01)
• DB9 connection cable
• CD with TimeScan THC and complete
TimeHub documentation
Clock cards 090-5551x-0x 1 (minimum)
2 (recommended)
Quartz or rubidium clock card
(order accordingly):
• Quartz 5 input (090-55511-01)
Note: This clock does not support
expansion shelves.
• Quartz 9 input (090-55512-02)
Note: This clock supports expansion
shelves.
• Rubidium 5 input (090-55513-01)
Note: This clock does not support
expansion shelves.
• Rubidium 9 input (090-55514-02)
Note: This clock supports expansion
shelves.
Output cards 090-55581-01 1 (minimum)
2 (recommended)
up to 8 per
master/remote
• Output card (090-55581-01)
DS1 output
module kit
990-55591-01 1 (minimum)
2 (recommended)
up to 7
DS1 and CC
total per
master/remote
• Round RJ-21 cable (060-55591-02)
• DS1 output module (090-55591-01)
CC output
module kit
990-55593-01 1 (minimum)
2 (recommended)
up to 7
DS1 and CC
total per
master/remote
• Round RJ-21 cable (060-55591-02)
• CC output module (090-55593-01)
