Symmetricom TimeHub 5500 System Manual

1
097-55501-01 Issue 6 – June 2003 69
2
5
3
Engineering & Ordering
Table 2-2 lists the basic components that should be ordered when
ordering an expansion shelf.
Table 2-2. Expansion Shelf Basic Components
Item Part Number Qty Included Items
Expansion shelf
kit
090-55505-02 1 • Expansion shelf (090-55505-03)
• Wirewrap panel (190-55595-01) x 1
• Wirewrap panel (190-55595-02) x 1
• Line terminator (190-55505-01) x 2
• Gender changer (128-55505-01)
• Connection cable (060-55505-01) x 2
• 19 in. and 23 in. mounting hardware
• System manual
• CD with TimeScan THC and complete
TimeHub documentation
Expansion
controller card
090-55545-01 1 (minimum)
2 (recommended)
• Expansion controller card
(090-55545-01)
Output cards 090-55581-01 1 (minimum)
2 (recommended)
up to 16
per
expansion shelf
• Output card (090-55581-01)
DS1 output
module kit for
expansion shelf
990-55591-02 1 (minimum)
2 (recommended)
up to 16
DS1 and CC
total per
expansion shelf
• Round RJ-21 cable (060-55591-02)
• DS1 output module (090-55591-02)
CC output
module kit for
expansion shelf
990-55593-01 1 (minimum)
2 (recommended)
up to 16
DS1 and CC
total per
expansion shelf
• Round RJ-21 cable (060-55591-02)
• CC output module (090-55593-02)
Blank panels for
output card
spaces
093-55598-02 16 minus amount
of output cards
• Optional to fill out output card space
