097-55501-01 Issue 6 – June 2003 153
2
5
3
Operational Verification & Configuration
4.10 Setting the Configuration to Factory
Defaults
If it is desired to reset all sychronization-related settings to their factory
default settings, use Procedure 4-10. This procedure will result in all
outputs being disabled (since that is the factory default), so it is not
recommended for a fully operational shelf.
27 If AOMERGE was set to Y, skip to Step 28. If AOMERGE was set to N, use the Edit
Equipment command to specify the port number for automatic output messages.
ED-EQPT:::<ctag>:::PORTAOX=a;
a = 5001 to 20000
Notes:
1. The PORTAOX value must be different than the PORTCMDSX value.
2. To verify the parameter, use the Retrieve Equipment command.
RTRV-EQPT:::<ctag>:::PARAMETER=PORTAOX;
28 Use the Copy Network Memory Security command to copy the data from auxiliary to
working memory.
CPY-MEM-SECU::NET:<ctag>::AUX,WKG;
End of Procedure
Procedure 4-10. Setting the Configuration to Factory Defaults
Step Action
1 Remove the clock cards from the shelf.
2 On one of the clock cards, observe the S1 switch 1 position (see Figure 4-8). Move S1
switch to the opposite position. If it was On, set it to Off. If it was Off, set it to On.
3 Insert this clock card into the shelf. Wait for it to come out of warm-up.
4 Remove the clock card and return the S1 switch 1 position to its original position. It should
end up in the same position as when you observed it in step 2.
Procedure 4-9. System Configuration (Cont’d)
Step Action
To Next Page
