120 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
3 To enable an output port of interest, the key steps are to put the card in-service, set the
output framing (if appropriate), and enable the specific port. The following steps will
accomplish this (note that it is easiest to accomplish this using TimeScan THC software -
see end of this step for details):
a. No output will be possible unless the output card is put in-service. This is accomplished
with the following TL1 command.
ED-EQPT::S1-OUTC:SV267:::INSRVC=Y;
In the above example, the card being put in service is located in expansion shelf 1 (S1-),
the card is in the C group (OUTC). SV267 is the ctag.
Here is the response to the above command:
SYMMBITS 02-07-11 10:35:54
M SV267 COMPLD
;
The INSRVC setting can be checked with the following TL1 command:
RTRV-EQPT::S1-OUTC:SV268:::PARAMETER=INSRVC;
Which produces the following response, in this showing that this card is in-service
(INSRVC = N would indicate that it is not in-service):
SYMMBITS 02-07-11 10:35:54
M SV268 COMPLD
"S1-OUTC::INSRVC = Y"
;
Procedure 4-6. Output Driver Card Installation (Cont’d)
Step Action
To Next Page
