097-55501-01 Issue 6 – June 2003 141
2
5
3
Operational Verification & Configuration
7
(cont’d)
To change priority if using terminal software, such as HyperTerminal, the TL1 general form
for priority setting is:
ED-SYNC::CLK-a:SV380:::PRIORITY=b;
Where a = 0 - 4 to identify the input (PRS = 0) and b = 0 - 9 to set the actual priority value.
To set input 2 priority to 3, type and send:
ED-SYNC::CLK-2:SV380:::PRIORITY=3;
Priority setting for input 2 can be retrieved with:
RTRV-SYNC::CLK-2:SV381:::PARAMETER=PRIORITY;
8 Set Framing for enabled DS1 inputs, if needed. DS1 inputs may have either D4 (also
known as SF) or ESF framing. TimeHub defaults DS1 inputs to expect D4 framing, so if
you have ESF inputs the setting needs to be changed.
To change framing if using TimeScan THC:
Use the T1 Framing row on the Configuration -> Input screen to change the framing of
selected input as needed.
To change framing if using terminal software, such as HyperTerminal, the TL1 general
form for framing setting is:
ED-SYNC::CLK-a:SV382:::ESF=b;
Where a = 1 - 8 to identify the input whose framing is being set (note that some TimeHub
models can accept up to eight DS1 inputs) and b = Y for ESF framing, N for D4 framing.
To set input 4 framing to ESF, type and send:
ED-SYNC::CLK-4:SV382:::ESF=Y;
The Framing setting for input 4 can be retrieved with:
RTRV-SYNC::CLK-4:SV383:::PARAMETER=ESF;
Procedure 4-9. System Configuration (Cont’d)
Step Action
