V/D
S
ERIES
R
EGULAR TESTS AND MAINTENANCE
Revision: 2.1 5-15
Restoring the last saved gain and offset values for the selected input.
Undoing a failed calibration!
Changes to the gain and offset values are only saved finally
once the menu has been exited. The last saved calibration can
be restored as long as you have not yet left the menu.
• Navigate to the Restore Values menu item and press the SET
button to restore the last saved gain and offset values.
• The DONE confirmation message appears in the display.
CALIBRATION
Change GainOffset
Calc. GainOffset
Restore Values
Chamb Press 124.4
SET EXIT
Fig. 8: Calibration: Restoring the last saved gain and offset values
• Press the EXIT button to exit the menu.
• Select another analogue input to be calibrated, or exit the calibration
menu and return to the basic display by repeatedly pushing the EXIT
button.
The SAVE... message is displayed and the calibration of the selected
value is stored.
