V/D S ERIES
S ERVICE SOFTWARE
Revision: 2.1 6-17
Get Values
button
Transfers the gain and offset values of the selected
sensor from the device to the PC.
Save Values
button
Transfers the gain and offset values of the selected
sensor from the PC to the device and stores them
temporarily.
The success of the calibration can be checked using the
displayed value of the current measurement.
Gain Max.
Maximum gain value.
Gain Min.
Minimum gain value.
Offset Max.
Maximum offset value.
Offset Min.
Minimum offset value.
Actual High
Reference value of the high measurement using external
test equipment.
Actual Low
Reference value of the low measurement using external
test equipment.
Read High
Device value during the high measurement.
Read Low
Device value during the low measurement.
Calc
button
Calculates the gain and offset values using the entered /
displayed high and low values.
Do not double-click the “Calc” button!
Burn
button
Transfers all gain and offset values from the calibration
into the non-volatile memory of the device.
Set Default
check box
Unused (future use).
Print
button
Prints the table of gain and offset values on the standard
printer connected to the PC.
Carry out the calibration as follows:
• Select the sensor (analogue input) to be calibrated from the “Analog
Inputs” table.
The current values for the gain and offset as well as the current device
display value are shown.
Only change the gain and offset settings manually
according to the specifications from Systec!
The calibration of a sensor can be changed manually using the
“Gain” and “Offset” fields.
