6-18 Revision: 2.1
• Click the “Get Values” button to load the gain and offset values for the
selected sensor onto the PC.
• Enter the high and low values into the corresponding fields:
“Actual High”: Reference value of the high measurement using
external test equipment.
“Read High”: Current device value during the high measurement.
Double-click the field to accept the currently displayed value.
“Actual Low”: Reference value of the low measurement using
external test equipment.
“Read Low”: Current device value during the low measurement.
Double-click the field to accept the currently displayed value.
• Click the “Calc” button.
The calculation is carried out with a single click on the
“Calc” button.
Double-clicking the button will lead to an incorrect calibration as
the calculation is then carried out twice.
The newly calculated gain and offset values are displayed.
• Click the “Save Values” button to transfer the new gain and offset
values into the temporary memory of the device.
The current measured value on the device is updated to match the new
straight line interpolation. You can check the success of the calibration
using the displayed value.
• Calibrate the next sensor as described above.
• After all sensors have been calibrated, click the “Burn” button.
The new calibration is written to the device's non-volatile memory and is
then available for use.
