V/D
S
ERIES
S
ERVICE SOFTWARE
6-28 Revision: 2.1
6.2.10 Parameters
You can view a list of all device parameters to check and modify individual
parameter values specifically (for the meaning of the parameters, see
chapter 8).
The following views are available:
− Program parameters (“Cycle”, see Fig. 22:)
− Global parameters (“Global”, see Fig. 24:)
For each view, you can choose between a short and a long view of the
parameter tables. In the long view, the minimum, maximum and default
values are displayed in addition to the value itself (see Fig. 23: or Fig. 25:).
The default values are planned for future use and are currently not used.
You can manually change the value of every parameter in the table and
then download them to the device.
All parameters are overwritten in each case!
Therefore, note the following sequence for modifying individual
parameters:
• Firstly, upload the set of parameters from the device
• Make any changes required
• Finally, download the changed set of parameters back to the
device
You can also save complete parameter sets as mdb files on the PC for
subsequent reuse.
mdb files
The file type for the parameter sets corresponds to the data
format for Microsoft Access. These have the suffix mdb and
should only be used with the Systec service software.
Note the direction of communication!
In the Systec service software,
always means
transmission from the PC to the device. The original data on the
device is overwritten.
