RUN MED: Service & Maintenance Manual - rev. 1.0
Page 9.20
MENU –I–
Par. Address Description Value Par. Address Description Value
I-7 107 Dig input 8 cfg 0 I-420 147 Out by serial en 0
I-50 108 Exp dig in 1 cfg 0 I-430 148 Exp OutBySer en 0
I-51 109 Exp dig in 2 cfg 0 I-450 149 An out by ser en 0
I-52 110 Exp dig in 3 cfg 500 150 coder enable 0 I- En 1
I-53 111 Exp dig in 4 cfg 0 I-501 151 Encoder ppr 720
I-100 112 Dig output 1 cfg 48 I-502 152 Enc channels cfg 1
I-101 113 Dig output 2 cfg 153 Enc spd mul fact 100 48 I-503
I-102 t 3 cfg e time 114 Dig outpu 48 I-504 154 Enc updat 0
I-103 115 Dig output 4 cfg 48 I-600 155 Serial link cfg 6
I-150 116 Exp DigOut 1 cfg 48 I-601 156 Serial link bps 4
I-151 117 Exp DigOut 2 cfg 48 I-602 157 Device address 1
I-200 118 An in 1 Type 1 I-603 158 Ser answer delay 1
I-201 119 An in 1 offset 0 I-604 159 Serial timeout 0
I-202 120 An in 1 gain 100 I-605 160 En timeout alm 1
I-203 121 An in 1 minimum 0 I-700 161 Option 1 type 0
I-204 122 An in 1 filter 1 I-701 162 Option 2 type 0
I-210 123 An in 2 Type 1 I-750 163 SBI address 3
I-211 124 An in 2 offset 0 I-751 164 CAN baudrate 0
I-212 125 An in 2 gain 100 I-752 165 SBI Profibus mod 2
I-213 126 An in 2 minimum 0 I-753 166 SBI CAN mode 0
I-214 127 An in 2 filter 1 I-760 167 SBI to Drv W 0 0
I-220 128 An in 3 Type 1 I-761 168 SBI to Drv W 1 0
I-221 129 An in 3 offset 0 I-762 169 SBI to Drv W 2 0
I-222 130 An in 3 gain 100 I-763 170 SBI to Drv W 3 0
I-223 131 An in 3 minimum 0 I-764 171 SBI to Drv W 4 0
I-224 132 An in 3 filter 1 I-765 172 SBI to Drv W 5 0
I-300 133 Analog out 1 cfg 0 I-770 173 Drv to SBI W 0 1
I-301 134 An out 1 offset 0 I-771 174 Drv to SBI W 1 2
I-302 135 An out 1 gain 100 I-772 175 Drv to SBI W 2 3
I-303 136 An out 1 filter 0 I-773 176 Drv to SBI W 3 4
I-310 137 Analog out 2 cfg 2 I-774 177 Drv to SBI W 4 5
I-311 138 An out 2 offset 0 I-775 178 Drv to SBI W 5 6
I-312 139 An out 2 gain 100
MENU –P–
Par. Address Description Value Par. Address Description Value
P-0 400 Cmd source sel 3 P-281 446 Brake res value 150
P-1 401 RUN input config 0 P-282 447 Brake res power 5
P-2 402 Reversal enable 1 P-283 448 Br res thermal K 160
P-3 403 Safety 1 P-300 449 DC braking level 0
P-20 404 Mains voltage 220 P-301 450 DCB lev fac src 0
P-21 405 Mains frequency 60 P-302 451 DC braking freq 0
P-40 406 Motor rated curr 70 P-303 452 DC braking start 0
P-41 407 Motor pole pairs 2 P-304 453 DC braking stop 0
P-42 408 Motor power fact 78 P-320 454 Autocapture mode 0
P-43 409 Motor stator R 100 120 P-321 456 Autocapture Ilim
P-44 410 Motor cooling 1 P-322 457 Demagnetiz time 8
P-45 411 Motor thermal K 30 P-323 458 Autocap f scan 10
P-60 412 V/f shape 1 P-324 459 Autocap V scan 2
P-61 413 Max out voltage 230 P-325 460 Enc for FlyRes 0
P-62 414 Base frequency 600 P-326 461 Fre for FlyRes 0
P-63 415 V/f interm volt 115 P-340 462 Undervoltage thr 50
P-64 416 V/f interm freq 300 P-341 463 Max pwrloss time 0
P-80 417 Max output freq 100 P-342 464 UV alarm storage 1
P-81 418 Min output freq 0 P-360 465 OV prevention 0
P-100 419 Slip compensate 90 P-380 466 Autoreset attmps 0
P-101 420 Slip comp filter 3 P-381 467 Autoreset clear 10
