Technogym Run MED - Disassembling the Display Fan

RUN MED: Service & Maintenance Manual - rev. 1.0
Page 7.6
7.5. DISASSEMBLING THE DISPLAY FAN
Figure 7.5-1
Carry out the procedure described in paragraph
7.1. “Disassembling the display”.
1. Back off the 4 screws a using a medium
Philips screwdriver.
2. Remove component b.
Figure 7.5-2
3. Remove the fan from the rear display
support.
To reassemble the display fan, carry out the
above steps in reverse order.
