Technogym Run MED - Disassembling the Sensors

RUN MED: Service & Maintenance Manual - rev. 1.0
Page 7.10
7.8. DISASSEMBLING THE SENSORS
Figure 7.8-1
. Turn off the machine and unplug the mains
For each sensor:
2. Back off the 2 screws a using a small Phillips
1
lead from the wall outlet.
screwdriver.
Figure 7.8-2
3. Lift up the top sensor.
4. Remove the lower sensor.
5. To disconnect the sensors, back off the two
screws b using a small Phillips screwdriver.
To reassemble the sensors, carry out the above
steps in reverse order.
