RUN MED: Service & Maintenance Manual - rev. 1.0
6.6.8. ERROR EM
The error is generated if the AT drive receives a software emergency signal via the 485 serial
communications link between the upper and lower assemblies, but does not receive the
corresponding emergency hardware signal via cables TRM-19 and TRM-20.
Does the error occur
frequently ?
YES
Replace the AT driver
board
Probable interf erence. The
machine is OK
NO
Does the machine resume
correct operation after being
turned of f f or 1 minute?
YES
1
Replace the AT driver
board
NO
EM
Follow the procedure step by step to correctly diagnose the problem. Take particular care with the
checks highlighted by circled numbers, which are described in detail below:
(1) Determine the frequency of the errors by counting the number of occurrences and by running
targeted checks. An error is considered frequent if it occurs 2 or 3 times a day.
Page 6.23
