RUN MED: Service & Maintenance Manual - rev. 1.0
12. APPENDIX
12.1. LIST OF CRITICAL SPARE PARTS
Technogym medical devices are identified by “Serial N” plates that allow them to be tracked
throughout the useful life-span of the device. Just as for products, there is also a list of so-called
“critical” components which, through the Serial N, must be guaranteed as traceable.
The list of these critical components is shown in the table below.
CODE COMPONENT
0WR00233AB Elevation motor
N0000001AA Tread belt motor
0WR00405AA Tread belt motor encoder
W0004467AA AT power supply box
0WK00394AA AT -UL- power supply box
W0004100AB AT driver box
W0004102AA AT -UL- driver box
0WQ00292AD Display board
0WQ00348AA C-Safe board
0WQ00269AA Hand sensor board
SW version Display program
SW version AT driver program
If a critical component listed in this table is replaced during a repair, maintenance or refurbishment,
this fact must be noted in the “Service report” by recording the tracking information for the new
component.
12.2. UPDATING THE SW
The machine SW is updated by writing to the contents of the FLASH EPROM on the ARM board
from an external PC connected to the CSAFE port on the machine, situated on the lower part of the
display panel.
After the Display SW update it is necessary to restore all the parameters to the default
values following the detailed instructions provided in paragraph 9.1.14. “Resetting
parameters to default values”.
After the lower electronic SW update it is necessary to restore all the parameters to the
default values following the detailed instructions provided in paragraph 9.2.2.3 “Default
setting”.
Page 12.1
