RUN MED: Service & Maintenance Manual - rev. 1.0
Page 4.2
4.2. CARDIO THEATER CONNECTION
rdioTheater unit must be provided with a power cable having the following pin-out:
The machine can be connected to the CardioTheater by means of the RJ45 connector on the CSafe
board. The Ca
RJ45 Connector Signal
5 +5 Vdc
7 Ground
ATTENTION: for the numbering of the pins, on RJ45 connector, please refer to the
diagram below:
4.3. PC LINK FOR PROGRAMMING
The machine can be connected to a PC for programming by means of the RJ45 connector on the
CSafe board.
he cable to use must be wired as follows: T
ATTENTION: for the numbering of the pins, on RJ45 connector, please refer to the
diagram below:
