Technogym Run MED - Disassembling the Display Board

RUN MED: Service & Maintenance Manual - rev. 1.0
Page 7.2
7.2. DISASSEMBLING THE DISPLAY BOARD
Figure 7.2-1
in paragraph
ng a small Phillips
oard, carry out the
above steps in reverse order.
Carry out the procedure described
7.1. “Disassembling the display”.
Then place the display on a work bench.
1. Unplug the connector indicated in the figure.
2. Back off the 5 screws a usi
screwdriver.
3. Remove the circuit board.
To reassemble the display b
