RUN MED: Service & Maintenance Manual - rev. 1.0
Page 7.22
7.17. DISASSEMBLING THE TREAD BELT GROUP
With these operations it is possible to disassemble:
• footrest;
• driving roller;
• tread belt motor drive-belt;
• running deck;
• driven roller;
• tread belt;
• shock absorbers.
In order to carry out these operations, it is necessary to slacken the tread-belt tension. If
the belt is to be used again, follow the instructions given in paragraph 8.2. “Tensioning a
used tread belt” to correctly re-tension the belt.
Figure 7.17-1
arry out the procedure described in paragraph
far e upper guard.
1. Remove the dust guard by pressing on the
C
7.9. “Disassembling the motor guard”, only as
as removing th
two hooks a.
Figure 7.17-2
. Back off the two screws b (one on each side)
3. screws c (one on each side)
using a 4-mm Allen wrench.
4. Remove the rear cover as indicated by the
arrows.
5. Then remove both footrests by pulling them
toward the back.
2
using a 4-mm Allen wrench.
Back off the two
Continued on following page →
