6.1.1.5. Serial Ports Test
The serial ports test checks the following communication ports:
• CSafe COM test;
• Low Kit COM test;
• TGS COM test.
Using the + and – speed keys, select the desired test item and confirm by pressing ENTER. The test
can have two outcomes:
• “Test Successful, press Enter to continue”: This means that the test was completed
successfully, i.e. that serial communications on the selected port are correct.
• “Error COMx, press Enter to continue”: This means that the outcome of the test was
negative: the message will specify COM1 in the case of the CSafe COM test, COM2 in the case
of communications with the low kit, or COM3 in the case of the TGS COM test.
The “TGS COM test” done on machine not provided with the key reader gives a fail
outcome. The same if the “CSafe COM test” is done on a machine which CSafe port is
not plugged with the monitor plug described at paragraph 4.4. “Monitor plug for CSafe
port”.
6.1.2. MANUAL TEST
This section groups together tests for manually checking the operation of certain peripheral devices.
After selecting the desired test item using the + and – speed keys, press ENTER to access the tests.
o exit test mode, hold down the CLEAR key for a few seconds. T
The various manual tests are described below.
6.1.2.1. Man. Keyboard Test
The manual keyboard test checks the functioning of all the keys on the keyboard. After accessing
the test by pressing ENTER, the message “Press all buttons (beep=OK)” appears on the display.
Pressing each key will produce an audible signal, if a key does not produce the “beep” it means it is
ot working properly. n
On Wellness TV machines, pressing the keys does not produce an audible signal, but if the key is
working correctly it lights up green.
6.1.2.2. Man. Inverter Test
The manual inverter test displays the values output by the inverter drive during movements of the
ead belt motor. The values displayed are: tr
lt motor drive frequency (x100); • Tread be
• Speed;
10); • Current (x
Voltage. •
During the test it is possible to vary the speed using the + and – speed keys, to check that the values
vary accordingly.
