RUN MED: Service & Maintenance Manual - rev. 1.0
Figure 7.14-7
3. Lock down the 2 grub screws i using a 1.5-
mm hex wrench to secure the encoder wheel
on the motor shaft.
Figure 7.14-8
4. Back off the two screws l using a small
Phillips screwdriver, and pull the spacer m
out of the encoder.
5. Reassemble the plastic cover.
The screws “l” have not to be
reassembled.
Page 7.19
