Tektronix TDS5052 User Manual

Appendix A: Specifications
TDS5000 Series User Manual
A-7
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Position range ± 5 divisions
Offset range 1MΩ coupling
SCALE range Offset range
1 mV/div to 99.5 mV/div ±1V
100 mV/div to 1V/div ±10 V
1.01 V/div to 10 V/div ±100 V
TDS5052/5054 50 Ω coupling
SCALE range Offset range
1 mV/div to 99.5 mV/div ±1V
100 mV/div to 1 V/div ±10 V
TDS5104 50 Ω coupling
SCALE range Offset range
1 mV/div to 50 mV/div ±0.5 V
50.5 mV/div to 99.5 mV/div ±0.25 V
100 mV/div to 500 mV/div ±5V
505 mV/div to 1 V/div ±2.5 V
Offset accuracy SCALE range Offset range
1 mV/div to 9.95 mV/div ±〈(0.2% ×| net offset |) +
1.5 mV + (0.1 div ×
V/div setting))
10 mV/div to 99.5 mV/div ±〈(0.35% ×| net offset |) +
1.5 mV + (0.1 div ×
V/div setting))
100 mV/div to 1 V/div ±〈(0.35% ×| net offset |) +
15 mV + (0.1 div × V/div
setting))
1.01 V/div to 10 V/div ±((0.25% ×| net offset |) +
150 mV) + (0.1 div ×
V/div setting))
At temperatures above
40 °C:
±((0.75% × | Net Offset |)
+ 150 mV + (0.1 div ×
V/div setting))
where, net offset = offset -- ( position × volts/division)
