Appendix A: Specifications
TDS5000 Series User Manual
A-9
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Average acquisition mode
(≥16 averages)
Absolute measurement of
any waveform point, and
High, Low, Max, and Min
measurements
±[1.5% + 1.0% × |net
offset /offset range|]×
|reading -- net offset |
+0.06div× V/div + offset
accuracy]
TDS 5104 with 2 mV/div --
3.98 mV/div:
±[1.5% + 3.0% × |net
offset /offset range|]×
|reading -- net offset + offset
accuracy + 0.06 div ×
V/div]
Delta voltage measurement
between any two points
acquired under the same
setup and ambient condi -
tions, and all other auto-
matic measurements
±[1.5% + 1.0% × |net
offset /offset range|×
|reading -- net offset| +
0.1 div × V/div setting +
0.3 mV]
TDS5104 with 2 mV/div --
3.98 mV/div:
±[1.5% + 3.0% × |net
offset /offset range|×
|reading -- net offset|
+ 0.1 div × V/div
+0.3mV]
where, net offset = offset -- (position × volts/division)
Nonlinearity, typical < 1 LSB differential, < 1 LSB integral, i ndependently
based
