TDS5000 Series User Manual

Table A- 2: Channel input and vertical specifications (Cont.)

Characteristic Description

Effective bits, typical Sine wave input at the indicated frequency and pk-pk

amplitude, at 50 mV/division and 25 °C

Signal and input conditions Effective bits

TDS5052, TDS5054 1 MHz, 9.2 div, 5 GS/s

sample rate, Sample ac-

quisition mode

6.8 bits

1 MHz, 9.2 div, 10 MS/s

sample rate, HiRes acquisi-

tion mode

9.1 bits

500 MHz, 6.5 div, 5 GS/s

sample rate, Sample ac-

quisition mode

6.5 bits

TDS5104 1 MHz, 9.2 div, 5 GS/s

sample rate, Sample ac-

quisition mode

6.6 bits

1 MHz, 9.2 div, 10 MS/s

sample rate, HiRes acquisi-

tion mode

9.0 bits

1 GHz, 6.5 div, 5 GS/s

sample rate, Sample ac-

quisition mode

4.7 bits
