SDI7 module troubleshooting

Verify the conﬁguration

To eliminate th

econﬁguration o f the module as the source of a problem, reset the

module to the factory default settings:

1. If necessary,

save the user conﬁguration in a preset. (The user conﬁguration

may already be saved as the power on preset.)

2. Restore the

factory default:

a. Press the MODULE button until TG8000 appears.

b. Press Enter to select Preset.

c. Press the up (▲)ordown(▼) arrow button to select RECALL.

d. Press the left (◄)orright(►) arrow button to select Factory Default.

e. Press the ENTER button to reset the instrument to the factory default

settings.

f. Press the BACK button to return the TG8000 main menu.

3. Check t

o see if the problem still exists.

If the problem has been ﬁxed, compare the settings between the factory default

and th

e user conﬁguration to ﬁnd the issue. (See Table 14-6.)

Table 14-6: SDI7 module factory default settings

Menu item name Settings

TEST SIG NAL 100% Color Bars

FORMAT

1080 59.94i

SAMPLE STRUCTURE/DEPTH YCbCr 4:2:2 10b

OUTPUT MODE HD (1920 x 1080)

MOVING PICTURE

H Step 0 Sample(s)

V Step 0 Line(s)

Period

1 Frame(s)

Random Disable

14–18 TG8000 Multiformat Test Signal Generator Service Manual
