ServicingtheWheelMotor
g036040
Figure67
1.Locknut
8.Couplingshaft15.Commutatorassembly
2.Dirtandwaterseal
9.Squareringseal(5each)
16.Endcover
3.Housingassembly10.Drivelink
17.Bolt(7each)
4.Back-upring11.Thrustbearing
18.Identicationtag
5.Back-upwasher12.Wearplate
19.Drivescrew(2each)
6.Shaftseal
13.Rotorassembly
20.Commutatorseal
7.Squarekey14.Manifoldassembly
Note:ThewheelmotorsoftheGroundsmaster360machinehavethesame
basicconstruction.Theleftwheelmotor(s)hasayellowdotontheportsideof
themotorhousing.Therightwheelmotor(s)hasareversetimedmanifold.
IMPORTANT
Donotinterchangethewheelmotorsonthemachine(e.g.,donot
puttherightmotorontheleftsideofthemachine).Ifnecessary,use
thePartsCatalogandPartNumberonthewheelmotortoidentify
therightandleftmotors.
Note:Forthewheelmotorrepairprocedures;refertotheParkerT orqmotor™
ServiceProcedure(TC,TB,TE,TJ,TF ,TG,TH,andTLSeries)attheendof
thischapter.
Groundsmaster360
Page4–87
HydraulicSystem:ServiceandRepairs
16225SLRevC

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
