Toro Groundsmaster 360 Service Manual

SpecialTools
YoucanorderthesespecialtoolsfromyourToroDistributor.
WheelHubPuller
g185941
Figure251
Thewheelhubpullerallowsyoutosafelyremovethewheelhubfromthewheel
motorshaft.
ToroPartNo.TOR6004
SteeringAlignmentTools
g036986
Figure252
1.Frontalignmenttool2.Rearalignmenttool
Thesteeringalignmenttoolsareusedtoensurethatthefrontandrearsteering
assembliesareproperlycenteredforsteeringassemblyservice.Thesetools
arerequiredforadjustmentofwheelalignmentorwhenreplacingthetierods.
Thesteeringalignmenttoolkitincludesthe2toolsnecessaryforuseonyour
machine.Oneofthetoolscentersthefrontsteeringassemblyandtheother
centerstherear.Thetoolkitalsoincludesnecessaryhardwareforattachingthe
toolstothemachine.
ToroPartNo.TOR6019
Thefrontalignmenttool(TOR6019-1)requiresthefollowinghardwarefor
attachmentpurposes:
Chassis:SpecialTools
Page6–4
Groundsmaster360
16225SLRevC

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
