Adjustments

TractionNeutralSensor

g186522

Figure187

1.Tractionneutralsensor3.Transmission

2.Neutralendplate4.Neutralarmassembly

g037790

Figure188

1.Tractionneutralsensor

4.Lockwasher(2each)

2.Neutralarmassembly5.Frontjamnut

3.Neutralendplate6.Rearjamnut

Thetractionneutralsensorisanormallyopenproximitysensorthatcloseswhen

thetractionpedalisintheNEUTRALposition.Thesensormountstoaneutral

endplate(Figure187).Thesensingplateforthetractionneutralsensoristhe

neutralarm.

Groundsmaster360

Page5–43

ElectricalSystem:Adjustments

16225SLRevC
