Toro Groundsmaster 360 - Service Screen

ServiceScreen
g187153
Figure177
1.Servicescreen(hours)4.Menu\backbutton
2.Left/rightbutton5.Serviceitems
3.Downbutton
Theservicescreen(Figure177)containsoperationalinformationofthemachine
includinghoursandcounts.Ifthecorrectpasscode(PIN)hasbeenentered
(refertotheProtectedMenusintheSettingsScreen(page5–24))theservice
screenallowsaccesstoinitiateamanualDPFregeneration,providesinformation
onDPFashaccumulation,andallowsresettingtheServiceDuetimer.T oscroll
throughthelistofservicerecordsandviewthecurrentvalues,pressthedown
button(asindicatedbytheatthebottomofthescreen).
Toreturntothepreviousscreen,pressthemenu/backbutton(asindicatedby
theatthebottomofthescreen).
Hoursprovidesaccesstothefollowinginformation:
•KeyOn(PINrequired)identiesthenumberofhoursthatthekeyswitch
hasbeenintheONposition.
•EngineRunidentiesthenumberofhoursthattheenginehasbeenrunning.
•PTOOnidentiesthenumberofhoursthatthemachinehasbeenoperated
withthecuttingdeckengaged.
•4-WheelSteer(PINrequired)identiesthenumberofhoursthatthemachine
hasbeeninthe4-wheelsteermode.
•ServiceDueidentiesthenumberofhoursbeforethenextscheduled
maintenanceisdue.Thisisacountdowntimerandthenumbersofhours
displayedwilldecreaseasthemachineisused.
•ServiceReset(PINrequired)identiesthetotalnumberofhoursbetween
scheduledmaintenanceintervals.ResettheServiceDuetimertotheservice
interval(250hours)bypressingtheleft/lightbutton(asindicatedbythe
at
thebottomofthescreen)andthenpressingthedownbutton(asindicatedby
theYesor
atthebottomofthescreen).
DPFRegeneration(PINrequired)allowsanoperatorortechniciantoinitiate
astationaryregenerationfortheexhaustsystemDPF(diesel-particulatelter)
onthemachineswithYanmardieselengines.IftheengineECUidenties
