ServicingthePTODriveshaftCrossandBearing
1.RemovethePTOdriveshaftfromthemachine;refertoRemovingthePTO
Driveshaft(page6–44).
IMPORTANT
Whenyouplacetheyokeinavise,clamplightlyonthesolidpartof
theyoketopreventdamage.Useaviseequippedwithsoftjaws.
2.Lightlyclamptheyokeinavise.Use2screwdriverstoremovethe4snap
ringsthatattachthebearingsattheinsideofeachyoke.Removetheyoke
fromthevise.
IMPORTANT
Supporttheyokeswhenremovingandinstallingthebearingsto
preventdamage.
3.Useapresstoremovethecrossandbearingsfromtheyokes,dothe
followingsteps:
A.Placeasmallsocketagainst1bearingandalargesocketagainstthe
yokeontheoppositeside.
B.Whileyousupportthelargesocket,applypressureonsmallsocketto
partiallypushtheoppositebearingintothelargesocket.
C.Removetheyokefromthepress,holdthepartiallyremovedbearingand
tapontheyoketocompletelyremovethebearing.
D.Repeattheprocessfortheremainingbearings.
E.Cleanandinspectallthecomponents.
g033696
Figure288
1.Endyoke
3.Snapring(4each)
2.Crossandbearingkit4.Shaftyoke
Groundsmaster360
Page6–47
