InstallingthePTODriveshaft
g037446
Figure287
1.Endyoke
5.Greasetting
2.Crossandbearingset
6.Yokeandsliptube
3.Greasetting
7.Endyoke
4.Yokeandshaft
1.PositionthePTOdriveshafttothemachine.
Note:Ensurethatthedriveshaftyokeandsliptube(item6inFigure287)is
towardthecuttingdeckgearboxshaft.
2.Alignthesplinesandrollpinholesofthedriveshaftyokeswiththe
transmissionandgearboxshafts.
3.SlidethePTOdriveshaftendyokesontothetransmissionPTOshaftand
gearboxshaft.
4.AttachtheendyokesofthePTOdriveshaftasfollows:
A.Installthe2rollpinstotheendyokesandshafts.
B.Installthe4boltsinthedriveshaftendyokes.Alternatedirectionthat
theboltisinstalledoneachyoke.
C.Installandtightenthe4locknutsthatattachtheendyokestothegearbox
andPTOshafts;torquethelocknutsto20to25N∙m(175to225in-lb).
5.LubricatethePTOdriveshaftgreasettings.
6.ConnectthewireharnesselectricalconnectortothePTOsolenoidvalve
coilconnector(item2inFigure285).
Chassis:ServiceandRepairs
Page6–46
Groundsmaster360
16225SLRevC
