Toro Groundsmaster 360 - Power Center Assembly (Machines with Operator Cab)

PowerCenterAssembly(MachineswithOperatorCab)
g037441
Figure296
1.Swelllatch(4each)
10.Foam
19.Startrelay
2.Flange-headscrew(4each)11.Tinnermannut(4each)
20.Leftfoam
3.Rightfoam
12.Foam21.Powercenterhousing
4.T opfoam13.Bottomfoam22.Screw(4each)
5.Mainpowerrelay
14.Trayfoam
23.Fuseblockdecal
6.Glowrelay
15.Powercentertrayassembly
24.Coverpanel
7.Clip(4each)16.EngineECU25.Cabplatform
8.Speednut(4each)17.Toroelectroniccontroller(TEC)
9.Foam
18.EGRrelay
Groundsmaster360
Page6–57
Chassis:ServiceandRepairs
16225SLRevC
