JackingInstructions

CAUTION

Failingtoproperlysupportthemachinewithappropriatejackstands

cancausethemachinetomoveorfallandcanresultinpersonal

injury.

Whenchangingtheattachments,tires,orperformingotherservices,

dothefollowingsteps:

•Usecorrectblocks,hoists,andjackstoraiseandsupportthe

machine.

•Parkthemachineonasolidlevelsurface,suchasaconcrete

oor.

•Beforeyouliftthemachine,removealltheattachmentsthatmay

interferewiththesafeandcorrectliftofthemachine.

•Alwaysblockthewheelswithchocks.

•Useappropriatejackstandstosupporttheraisedmachine.

•Donotusethecuttingdeckorimplementasajackingpoint.

RaisingtheFrontoftheMachine

g188106

Figure2

1.Frontaxlepivot2.Fronttire

1.Settheparkingbrakeandblockthe2reartireswithchockstopreventthe

machinefrommoving.

2.Positionthejacksecurelyunderthefrontaxlepivot.

3.Useajacktoraisethefrontofthemachine.

IMPORTANT

Donotsupportthemachineonthefrontsteeringforkorfrontwheel

motors.

4.Afterraisingthefrontofthemachine,useappropriatejackstandsunderthe

frametosupportthefrontofthemachine.

Groundsmaster360

Page1–7

Safety:JackingInstructions

16225SLRevC
