Toro Groundsmaster 360 Service Manual

Whentheparkingbrakeisnotset(brakelatchnotengaged),theparkingbrake
detentispositionednearthetargetendoftheparkingbrakesensorsothatthe
sensorisclosed.Theparkingbrakedetentismovedawayfromthesensorwhen
theparkingbrakeisset(brakelatchengaged)causingthesensortoopen.
AdjustingtheParkingBrakeSensor
1.Whentheparkingbrakeisnotapplied(brakelatchnotengaged),thegap
betweentheparkingbrakesensorandthetabontheparkingbrakedetent
shouldbe3.8to4.7mm(0.148to0.188inch).
2.Ifthegapisincorrect,loosenthejamnutsthatsecurethesensortothe
brakelever.Positionthesensorwithjamnutstoallowcorrectgapbetween
thesensorandthebrakedetenttab.Tightenthejamnutstosecurethe
adjustment.Torquethejamnutsto18.4to22.4N∙m(162to198in-lb).
Afterthejamnutsaretightened,ensurethatclearancebetweenthehead
oftheparkingbrakesensorandthetabontheparkingbrakedetenthas
notchanged.
3.CheckthattheLEDonthecableendoftheparkingbrakesensoris
illuminatedwhentheparkingbrakeisnotapplied(brakelatchnotengaged).
TheLEDshouldnotbeilluminatedwhentheparkingbrakeisset(brake
latchisengaged).
4.Afteradjustmenttotheparkingbrakesensor,usetheInfoCenterdisplayto
verifythattheparkingbrakesensorandcircuitwiringarefunctioningcorrectly;
refertoUsingtheInfoCenterDisplayforTroubleshooting(page5–30).
SteeringHomeSensor
g037789
Figure191
1.Frontaxle
5.Steeringhomesensor
2.T argetbracket
6.Sensorbracket
3.Leftfrontsteeringfork7.Lockwasher(2each)
4.Wheelmotor
8.Jamnut(2each)
ElectricalSystem:Adjustments
Page5–46
Groundsmaster360
16225SLRevC

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
