Toro Groundsmaster 360 Service Manual

ServicingtheDeckLiftManifoldAssembly(continued)
WARNING
Ifthedeckliftmanifoldisattachedtothemachine,ensurethatthe
cuttingdeckisfullyloweredandsupportedbeforelooseningthe
hydrauliclines,cartridgevalves,orplugsfromthedeckliftmanifold
assembly.
Ifthedeckisraisedasthedeckliftmanifoldcomponentsare
loosened,thedeckmaydropunexpectedly.
IMPORTANT
The2solenoidvalvesinthedeckliftmanifoldaredifferent.Labelthe
valvesbeforeremovalsothatthevalvescanbecorrectlyinstalled
intothemanifold.
Forthecartridgevalveserviceprocedures,refertoServicingtheCartridge
ValvesinaControlManifold(page4–134).RefertoFigure152fordecklift
manifoldassemblycartridgevalve,solenoidnut,andpluginstallationtorque.
HydraulicSystem:ServiceandRepairs
Page4–164
Groundsmaster360
16225SLRevC

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
