8 Stakeout Workflow
Roads
The road or alignment that you want to stake out must be part of the currently loaded design.
There are multiple ways to get a road into a design:
l
From a road corridor created in the Business Center HCE software and exported through the
Field Data menu.
l
Convert LandXML files with the SCS Data Manager.
l
Export a road from the Terramodel® software.
If you have the Road module installed and a Road design loaded, you can select a road/alignment
from the map or from the list in the Stake menu and select one of the three road staking methods
that are available:
l
Roadway feature staking(see page 75)
l
Catch point staking(see page 79)
l
Location on Surface(see page 82)
If no Roading option is installed on the controller, a warning appears.
The grade stake marking preferences in the Stakeout Settings also apply to staking roadways.
Staking methods for catch point staking can be set in the Trimble icon menu under Settings / Catch
Point Marking while in the Catch Point staking mode.
Roads
The road or alignment that you want to stake out must be part of a design map in the currently
loaded design. There are multiple ways to get a road into a design:
l
From a road corridor created in the Business Center HCE software and exported through the
Field Data menu.
l
Converting LandXML files with the SCS Data Manager.
l
Exporting a road from the Terramodel software.
If you have the Road module installed and a Road design loaded, you can select a road/alignment
from the map or from the list in the Stake menu and select one of the three road staking methods
that are available:
l
Feature
l
Catch point
l
Location
If no Roading option is installed on the controller, a warning appears.
Trimble SCS900 Site Controller Software User Guide 73
