RXM-RAWX continued
Byte Offset Number
Format
Scaling Name Unit Description
24 + 32*N R8 - cpMes cycles Carrier phase measurement [cycles]. The carrier
phase initial ambiguity is initialized using an
approximate value to make the magnitude of
the phase close to the pseudorange
measurement. Clock resets are applied to both
phase and code measurements in accordance
with the RINEX specification.
32 + 32*N R4 - doMes Hz Doppler measurement (positive sign for
approaching satellites) [Hz]
36 + 32*N U1 - gnssId - GNSS identifier (see Satellite Numbering for a
list of identifiers)
37 + 32*N U1 - svId - Satellite identifier (see Satellite Numbering)
38 + 32*N U1 - sigId - New style signal identifier (see Signal Identifiers).
39 + 32*N U1 - freqId - Only used for GLONASS: This is the frequency
slot + 7 (range from 0 to 13)
40 + 32*N U2 - locktime ms Carrier phase locktime counter (maximum
64500ms)
42 + 32*N U1 - cno dBHz Carrier-to-noise density ratio (signal strength)
[dB-Hz]
43 + 32*N X1 0.
01*2^n
prStdev m Estimated pseudorange measurement standard
deviation (see graphic below)
44 + 32*N X1 0.004 cpStdev cycles Estimated carrier phase measurement standard
deviation (note a raw value of 0x0F indicates the
value is invalid) (see graphic below)
45 + 32*N X1 0.
002*2^
n
doStdev Hz Estimated Doppler measurement standard
deviation. (see graphic below)
46 + 32*N X1 - trkStat - Tracking status bitfield (see graphic below)
47 + 32*N U1 - reserved2 - Reserved
End of repeated block
Bitfield recStat
This graphic explains the bits of recStat
UBX-18010854 - R04 Advance Information Page 176 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
