u-blox ZED-F9P User Manual

u-blox ZED-F9P Interface Description - Manual
Advance Information
Name Description
saveAll
Save all current configuration to the selected non-volatile memory if any bit is set
Bitfield loadMask
This graphic explains the bits of loadMask
Name Description
loadAll
Discard current configuration and rebuilt it from lower non-volatile memory layers if any bit is set
Bitfield deviceMask
This graphic explains the bits of deviceMask
Name Description
devBBR
Battery Backed RAM
devFlash
Flash
devEEPROM
EEPROM
devSpiFlash
SPI Flash
5.9.3 UBX-CFG-DAT (0x06 0x06)
5.9.3.1 Set User-defined Datum.
Message
UBX-CFG-DAT
Description
Set User-defined Datum.
Firmware
Supported on:
• u-blox 9 with protocol version 27
Type
Set
Comment
This message is deprecated in protocol versions greater than 23.01. Use UBX-CFG-
VALSET, UBX-CFG-VALGET, UBX-CFG-VALDEL instead.
See the Legacy UBX Message Fields Reference for the corresponding configuration item.
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x06 0x06 44
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
UBX-18010854 - R04 Advance Information Page 41 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
