5.15.3 UBX-RXM-RAWX (0x02 0x15)
5.15.3.1 Multi-GNSS Raw Measurement Data
Message
UBX-RXM-RAWX
Description
Multi-GNSS Raw Measurement Data
Firmware
Supported on:
• u-blox 9 with protocol version 27 (only with High Precision GNSS products)
Type
Periodic/Polled
Comment
This message contains the information needed to be able to generate a RINEX 3 multi-
GNSS observation file.
This message contains pseudorange, Doppler, carrier phase, phase lock and signal quality
information for GNSS satellites once signals have been synchronized. This message supports
all active GNSS.
The only difference between this version of the message and the previous version (UBX-
RXM-RAWX-DATA0) is the addition of the version field.
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x02 0x15 16 + 32*numMeas
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
0 R8 - rcvTow s Measurement time of week in receiver local
time approximately aligned to the GPS time
system. The receiver local time of week, week
number and leap second information can be
used to translate the time to other time systems.
More information about the difference in time
systems can be found in RINEX 3
documentation. For a receiver operating in
GLONASS only mode, UTC time can be
determined by subtracting the leapS field from
GPS time regardless of whether the GPS leap
seconds are valid.
8 U2 - week weeks GPS week number in receiver local time.
10 I1 - leapS s GPS leap seconds (GPS-UTC). This field
represents the receiver's best knowledge of the
leap seconds offset. A flag is given in the recStat
bitfield to indicate if the leap seconds are
known.
11 U1 - numMeas - Number of measurements to follow
12 X1 - recStat - Receiver tracking status bitfield (see graphic
below)
13 U1 - version - Message version (0x01 for this version).
14 U1[2] - reserved1 - Reserved
Start of repeated block (numMeas times)
16 + 32*N R8 - prMes m Pseudorange measurement [m]. GLONASS inter
frequency channel delays are compensated with
an internal calibration table.
UBX-18010854 - R04 Advance Information Page 175 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
