u-blox ZED-F9P User Manual

u-blox ZED-F9P Interface Description - Manual
Advance Information
5.12.7 UBX-MGA-INI (0x13 0x40)
5.12.7.1 UBX-MGA-INI-POS_XYZ
Message
UBX-MGA-INI-POS_XYZ
Description
Initial Position Assistance
Firmware
Supported on:
• u-blox 9 with protocol version 27
Type
Input
Comment
Supplying position assistance that is inaccurate by more than the specified
position accuracy, may lead to substantially degraded receiver performance.
This message allows the delivery of initial position assistance to a receiver in cartesian ECEF
coordinates. This message is equivalent to the UBX-MGA-INI-POS_LLH message, except
for the coordinate system. See the description of AssistNow Online for details.
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x13 0x40 20
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
0 U1 - type - Message type (0x00 for this type)
1 U1 - version - Message version (0x00 for this version)
2 U1[2] - reserved1 - Reserved
4 I4 - ecefX cm WGS84 ECEF X coordinate
8 I4 - ecefY cm WGS84 ECEF Y coordinate
12 I4 - ecefZ cm WGS84 ECEF Z coordinate
16 U4 - posAcc cm Position accuracy (stddev)
5.12.7.2 UBX-MGA-INI-POS_LLH
Message
UBX-MGA-INI-POS_LLH
Description
Initial Position Assistance
Firmware
Supported on:
• u-blox 9 with protocol version 27
Type
Input
Comment
Supplying position assistance that is inaccurate by more than the specified
position accuracy, may lead to substantially degraded receiver performance.
This message allows the delivery of initial position assistance to a receiver in WGS84
lat/long/alt coordinates. This message is equivalent to the UBX-MGA-INI-POS_XYZ
message, except for the coordinate system. See the description of AssistNow Online for
details.
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x13 0x40 20
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
0 U1 - type - Message type (0x01 for this type)
1 U1 - version - Message version (0x00 for this version)
2 U1[2] - reserved1 - Reserved
UBX-18010854 - R04 Advance Information Page 118 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
