u-blox ZED-F9P Interface Description - Manual
Advance Information
CFG-UART2-* Configuration Items continued
Configuration Item Key ID Type Scale Unit Description
CFG-UART2-REMAP 0x10530006 L - - UART2 Remapping
Constants for CFG-UART2-STOPBITS
Constant Value Description
HALF 0 0.5 stopbits
ONE 1 1.0 stopbits
ONEHALF 2 1.5 stopbits
TWO 3 2.0 stopbits
Constants for CFG-UART2-DATABITS
Constant Value Description
EIGHT 0 8 databits
SEVEN 1 7 databits
Constants for CFG-UART2-PARITY
Constant Value Description
NONE 0 No parity bit
ODD 1 Add an odd parity bit
EVEN 2 Add an even parity bit
6.7.28 CFG-UART2INPROT: Input Protocol Configuration of the UART2 Interface
Input protocol enable flags of the UART2 interface.
CFG-UART2INPROT-* Configuration Items
Configuration Item Key ID Type Scale Unit Description
CFG-UART2INPROT-UBX 0x10750001 L - - Flag to indicate if UBX should be an
input protocol on UART2
CFG-UART2INPROT-NMEA 0x10750002 L - - Flag to indicate if NMEA should be an
input protocol on UART2
CFG-UART2INPROT-RTCM3X 0x10750004 L - - Flag to indicate if RTCM3X should be
an input protocol on UART2
6.7.29 CFG-UART2OUTPROT: Output Protocol Configuration of the UART2 Interface
Output protocol enable flags of the UART2 interface.
CFG-UART2OUTPROT-* Configuration Items
Configuration Item Key ID Type Scale Unit Description
CFG-UART2OUTPROT-UBX 0x10760001 L - - Flag to indicate if UBX should be an
output protocol on UART2
CFG-UART2OUTPROT-NMEA 0x10760002 L - - Flag to indicate if NMEA should be an
output protocol on UART2
CFG-UART2OUTPROT-RTCM3X 0x10760004 L - - Flag to indicate if RTCM3X should be
an output protocol on UART2
UBX-18010854 - R04 Advance Information Page 229 of 259
