Name Description
action
Transaction action to be applied:
0: Transactionless UBX-CFG-VALDEL: In the next UBX-CFG-VALDEL, it can be either 0 or 1. If a transaction has not
yet been started, the incoming configuration is applied. If a transaction has already been started, cancels any
started transaction and the incoming configuration is applied.
1: (Re)Start deletion transaction: In the next UBX-CFG-VALDEL, it can be either 0, 1, 2 or 3. If a transaction has not
yet been started, a transaction will be started. If a transaction has already been started, restarts the transaction,
effectively removing all previous non-applied UBX-CFG-VALDEL messages.
2: Deletion transaction ongoing: In the next UBX-CFG-VALDEL, it can be either 0, 1, 2 or 3.
3: Apply and end a deletion transaction: In the next UBX-CFG-VALDEL, it can be either 0 or 1.
5.9.26 UBX-CFG-VALGET (0x06 0x8B)
5.9.26.1 Get Configuration Items
Message
UBX-CFG-VALGET
Description
Get Configuration Items
Firmware
Supported on:
• u-blox 9 with protocol version 27
Type
Poll Request
Comment
This message is used to read configuration items from the receiver. It returns the
configuration data for the specified items and layer.
A UBX-CFG-NAK message is returned in case one or more items are unknown to the
receiver or when the number of requested items is greater than 64. Otherwise a UBX-CFG-
ACK message is returned.
The configuration items are identified by their configuration key IDs.
See Receiver Configuration for details.
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x06 0x8B 4 + 4*N
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
0 U1 - version - message version, set to 0
1 U1 - layer - The layers from which the configuration items
should be retrieved:
0 - RAM layer
1 - BBR layer
2 - Flash layer
7 - Default layer
2 U1[2] - reserved1 - Reserved
Start of repeated block (N times)
4 + 4*N U4 - keys - configuration key ID selected for retrieval
End of repeated block
UBX-18010854 - R04 Advance Information Page 85 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
