u-blox ZED-F9P User Manual

u-blox ZED-F9P Interface Description - Manual
Advance Information
• if the layers bitfield does not specify a layer to delete a value from
Notes:
• Any request for another UBX-CFG- message type (including UBX-CFG-VALSET and UBX-
CFG-VALGET) will cancel any started transaction, and no configuration is applied.
• This message can be sent with no keys to delete for the purposes of managing the
transaction state transition.
• If a key is sent multiple times within the same message or within the same transaction,
then the value is effectively deleted only once.
• Attempting to delete items that have not been set before, or that have already been
deleted, is considered a valid request
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x06 0x8C 4 + 4*N
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
0 U1 - version - Message version, set to 1
1 X1 - layers - The layers where the configuration should be
deleted from (see graphic below)
2 X1 - transaction - Transaction action to be applied: (see graphic
below)
3 U1 - reserved1 - Reserved
Start of repeated block (N times)
4 + 4*N U4 - keys - Configuration Item IDs of the Configuration
Items to be deleted
End of repeated block
Bitfield layers
This graphic explains the bits of layers
Name Description
bbr
Delete configuration from the BBR layer
flash
Delete configuration from the Flash layer
Bitfield transaction
This graphic explains the bits of transaction
UBX-18010854 - R04 Advance Information Page 84 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
